Tulsimer ® MB-106UP为阶核子级抛光树脂, 是由核子级强酸型阳离子Tulsimer ® T-46Li 及核子级强碱型阴离子 Tulsimer ® A-33OH 以1:2 体积比的剂量比例 , 预先混合的混床级离子交换树脂,专门提供给超纯水系统抛光用
·重要参数
|
Tulsimer ®T-46 (阳) |
Tulsimer ®A-33 (阴) |
|
|
型式(Type) |
强酸性阳离子交换树脂 (Strong acid Cation exchange resin) |
强碱性阴离子交换树脂 (Strong base Anion exchange resin) |
|
主体结构(Matrix Structure) |
苯乙烯(Cross linked polystyrene) |
苯乙烯(Cross linked polystyrene) |
|
功能基 (Functional Group) |
硫酸基(Sulfonic acid) |
4级胺(Quaternary ammonium Type I) |
|
物理性貭(Physical Form) |
球状颗粒(Moist spherical beads) |
球状颗粒(Moist spherical beads) |
|
离子型式(Ionic form supplied) |
氢(Hydrogen) |
氢氧(Hydroxide) |
|
粒径范围(U.S.mesh in wet) |
16 to 50 |
16 to 50 |
|
粒度范围 (Particle Size) |
0.3 to 1.2 mm |
0.3 to 1.2 mm |
|
微粒含量(Fines Content) |
穿过US 50 Mesh小于0.5% (Less than 0.5% passing through 50 U.S.mesh) |
穿过US 50 Mesh小于0.5% (Less than 0.5% passing through 50 U.S.mesh) |
|
总交换容量 (Total Exch. Capacity) |
1.8 meq/ml minimum of 99% in hydrogen form |
1.0 meq/ml minimum of 90% in hydroxide form and less than 1% in chloride form |
|
PH范围 (pH Range) |
0 to 14 |
0 to 14 |
|
允许温度 (Temp. Stability) |
120°C |
60°C |
|
微粒含量(Fines Content) |
穿过US 50 Mesh小于0.5% (Less than 0.5% passing through 50 U.S.mesh) |
穿过US 50 Mesh小于0.5% (Less than 0.5% passing through 50 U.S.mesh) |
|
总交换容量 (Total Exch. Capacity) |
1.8 meq/ml minimum of 99% in hydrogen form |
1.0 meq/ml minimum of 90% in hydroxide form and less than 1% in chloride form |
|
PH范围 (pH Range) |
0 to 14 |
0 to 14 |
|
允许温度 (Temp. Stability) |
120°C |
60°C |
|
溶解率 (Solubility) |
Insoluble in all common solvents |
Insoluble in all common solvents |
|
溶出有机物(Organic leachable) |
Less than 0.2 mg KMNO4 per ml of wet resin |
Less than 0.2 mg KMNO4 per ml of wet resin |
|
密度Backwash settled density |
Approx.750 gm/liter |
Approx.750 gm/liter |
|
不纯物(Impurities) |
Fe=50 ppm(max) |
Fe=50 ppm(max) |
|
Cu=50 ppm(max) |
Cu=50 ppm(max) |
|
|
Pb=50 ppm(max) |
Pb=50 ppm(max) |
|
|
球粒强度(Bead strength) |
Avg. not less than 300g/bead by Chatillon test (ASTM Standard) |
|
