尺寸规格表
|
Style No. |
Size尺寸 |
ID.外径 |
ID Tolerance |
OD内径 |
Wall Thickness |
Wall THK Tolerance |
|
TT001 |
3*2mm |
3mm |
±0.05 mm |
2 mm |
0.5 mm |
±0.05 mm |
|
TT002 |
4*3mm |
4mm |
±0.05 mm |
2 mm |
1.0 mm |
±0.05 mm |
|
TT003 |
6*4mm |
6mm |
±0.05 mm |
4 mm |
1.0 mm |
±0.05 mm |
|
TT004 |
8*6mm |
8mm |
±0.08 mm |
6 mm |
1.0 mm |
±0.08 mm |
|
TT005 |
10*8mm |
10mm |
±0.08 mm |
8 mm |
1.0 mm |
±0.08 mm |
|
TT006 |
12*10mm |
12mm |
±0.10 mm |
10 mm |
1.0 mm |
±0.10 mm |
|
TT007 |
25*22mm |
25mm |
±0.2mm |
22mm |
1.5mm |
±0.12mm |
|
TT008 |
1/8” |
3.175 mm |
±0.100 mm |
2.175 mm |
0.5 mm |
±0.080 mm |
|
TT009 |
1/4” |
6.35 mm |
±0.100 mm |
4.35 mm |
1.0 mm |
±0.102 mm |
|
TT010 |
3/8” |
9.53 mm |
±0.127 mm |
6.39 mm |
1.57 mm |
±0.127 mm |
|
TT011 |
1/2” |
12.70 mm |
±0.127 mm |
9.56 mm |
1.57 mm |
±0.127 mm |
|
TT012 |
3/4” |
19.05 mm |
±0.127 mm |
15.91 mm |
1.57 mm |
±0.127 mm |
|
TT013 |
1” |
25.40 mm |
±0.127 mm |
22.26 mm |
1.57 mm |
±0.127 mm |
|
TT014 |
1-1/4” |
31.75 mm |
±0.127 mm |
28.15 mm |
1.80 mm |
±0.127 mm |
|
TT015 |
1-1/2” |
38.1 mm |
±0.203 mm |
33.73 mm |
2.18 mm |
±0.203 mm |
